Masinloc power station
| Part of the Global Coal Plant Tracker, a Global Energy Monitor project. |
| Related coal trackers: |
Masinloc power station is an operating power station of at least 1025-megawatts (MW) in Bani, Masinloc, Zambales, Central Luzon, Philippines with multiple units, some of which are not currently operating.
Location
Table 1: Project-level location details
| Plant name | Location | Coordinates (WGS 84) |
|---|---|---|
| Masinloc power station | Bani, Masinloc, Zambales, Central Luzon, Philippines | 15.5640555, 119.9230603 (exact) |
The map below shows the exact location of the power station.
Unit-level coordinates (WGS 84):
- Unit 1, Unit 2: 15.5640555, 119.9230603
- Unit 3, Unit 4, Unit 5: 15.5638449, 119.9191543
Project Details
Table 2: Unit-level details
| Unit name | Status | Fuel(s) | Capacity (MW) | Technology | Start year |
|---|---|---|---|---|---|
| Unit 1 | Operating | coal: bituminous | 330 | subcritical | 1998 |
| Unit 2 | Operating | coal: bituminous | 344 | subcritical | 1999 |
| Unit 3 | Operating | coal: bituminous | 351.8 | subcritical | 2020 |
| Unit 4 | Construction[1] | coal: bituminous | 350 | supercritical | 2025 (planned)[2] |
| Unit 5 | Pre-permit[2] | coal: bituminous | 350 | supercritical | 2026 (planned)[2] |
Table 3: Unit-level ownership and operator details
| Unit name | Owner | Parent |
|---|---|---|
| Unit 1 | Masinloc Power Partners Co Ltd [100%] | San Miguel Corp |
| Unit 2 | Masinloc Power Partners Co Ltd [100%] | San Miguel Corp |
| Unit 3 | Masinloc Power Partners Co Ltd [100%] | San Miguel Corp |
| Unit 4 | Masinloc Power Partners Co Ltd [100%] | San Miguel Corp |
| Unit 5 | Masinloc Power Partners Co Ltd [100%] | San Miguel Corp |
Project-level coal details
- Coal source(s): Australia and Indonesia
Existing Units 1 & 2
In 1990, the Philippine government's National Power Corporation (NPC) undertook the Masinloc Thermal Power Project with financing from the Asian Development Bank (ADB) and the Export-Import Bank of Japan. Subsequent local opposition and protests created problems for the plant's developers with land acquisition, resettlement, and obtaining an environmental compliance certificate, thus significantly delaying the project's construction. Eventually, President Fidel Ramos used emergency powers to push the plant's construction through. 198 families were displaced to make way for the plant.[3] In 2011, Masinloc Vice Mayor Jeffrey Bautista recalled that Ramos “had to send troops to control the crowd here.”[4]
In 1992, Father Shay Cullen reported on this opposition, stating that "the people of Masinloc and Zambales don't want this power, the protest against it, they object strenuously that their health and that of their children is to be sacrificed and their land, sea and skies polluted and poisoned. ... They are starting an international letter campaign to Mr. Kimi Masa Tarumitzu and the donor governments of the ADB to get the project stopped. Bishop Deogracias and the entire clergy of Zambales province have taken their stand with the people and have denounced the project as being environmentally unsound."[5]
In Dec. 1993, more than 500 people traveled six hours from Masinloc to participate in a protest at the Manila office of the Export-Import Bank of Japan, calling on the bank to retract its financing for the project. The protest was organized by Bani United Community for Progress (BUCUPI), Sama-sama Laban sa Planta, and the Social Action Committee of Masinloc (a Catholic church group). Mila Umayam, a protest leader, called the financing by the Japanese bank "the second invasion of the Japanese regime." Kazio Sunaga, first secretary of the Japanese Embassy in Manila, stated that they were "urging the Philippine government to have intensive talks with local people" in Masinloc in order to resolve the dispute.[6][7]
In June 1994, the NPC used a "Writ of Possession" to take possession of the land of eight landowners who had refused to sell in order to make way for the plant; the Iba clergy said that the NPC pressured landowners, offered varying rates for their land, and offered land at a relocation site that did not match the value of the land that the villagers had to give up.[8] The project broke ground in July 1994, in a ceremony presided over by Pres. Ramos, while more than 1,000 people, led by Bishop Deogracias Iniguez and Father James Laquindanum, protested outside. Protesters said that they would continue with protests and legal action to prevent the construction from proceeding.[8]
The Asian Development Bank issued its initial loan for the project in Dec. 1994; a 1995 ADB study concluded that "no significant potential health risk will arise from the atmospheric emissions from the operation of the Project because measures have been instituted to ensure that the plant's emissions and effluents will be will within [the standards of the Philippine government's Department of Environment and Natural Resources]."[9] The plant went online in 1998. Coal for the plant was reportedly source from Australia and Indonesia.[10]
After the Philippine government incurred $687 million in debt (much of it from the ADB) due to the plant's construction, the ADB in 2001 gave the Philippine government a $300 million loan in exchange for passing the Electric Power Industry Restructuring Act, which called for the privatization of state-owned power plants. The government's NPC sold the Masinoc plant to AES in April 2007 for $930 million. Critics such as the Freedom from Debt Coalition accused the ADB of profiteering from the privatization of the Philippine power industry.[11]
In Nov. 2005, during a nonviolent Greenpeace protest that was organized after discussions on expanding the plant began, a German Greenpeace activist, Jens Loewe, was hit by a crowbar in the face and beaten by armed guards at the Masinloc plant. Three other activists were also injured after being hit by stones thrown by the guards; the guards allegedly also fired warning shots into the air.[12][3]
In April 2023, the DOE's list of existing power plants showed that the new installed (nameplate) capacity of Units 1 and 2 were 330.1 MW and 344 MW, respectively.[13]
Expansions (Units 3, 4, and 5)
Units 3 & 4 expansion
In 2011 AES Corp. announced plans for a $1-billion expansion to double the existing capacity of the 600 MW Masinloc power station. The first phase of the project would involve the construction of an additional 300 MW coal plant, expected to be completed by 2015. The second phase of the project would construct the remaining 300 MW to go online by 2018, if there was demand.[14]
City officials opposed the expansion. In 2011, Mayor Desiree Edora described the negative effects of the existing plant, stating that local farmers "say their crops have been affected. The fruits of trees, especially mango trees, for which we are well-known for, have been stunted. They do not grow as big as before. Fishermen report less catch." Vice Mayor Bautista stated that, when the plant was constructed, “we knew that it would be bad for the environment as well as ourselves.”[4]
In June 2012, AES stated that it had an “environmental permit in place."[15] As of September 2014, AES was negotiating the engineering, procurement, & construction (EPC) contract with potential contractors; the company hopes to break ground in 2015, and complete the project in 2018. The project's cost has been upped to $1.2 billion.[16][17]
In June 2014, AES sold a 45% stake in its Philippine operations (including the Masinloc plant) to the Thai company Electricity Generating Public Company (EGCO Group).[18]
POSCO appeared to be awarded the Engineering, Procurement, and Construction (EPC) package for the expansion project.[19]
Construction began on Unit 3 in March 2016 with completion scheduled for 2019. Investors included EGCO Group, AES Corporation and the International Finance Corporation (IFC), in the proportion of 40.95%, 51% and 8.05% respectively.[20] In August 2016, AES selected U.S. firm POWER Engineers as engineering contractor on the project.[21] As of September 2018 Unit 3 was scheduled for commissioning in March 2019.[22] In March 2019 the Department of Energy gave a target testing and commissioning date of July 2019 for Unit 3.[23] Test commissioning of Unit 3 occurred in July 2019 and it was scheduled to be commissioned in October 2019.[24] In December 2019 the DOE listed a Q1 2020 commissioning date for Unit 3.[25] In August 2020 it was reported that Unit 3 would be commissioned in December 2020 and Unit 4 in 2024.[26] In January 2021 it was reported that Unit 3 was operating and that Unit 4 was now being developed as a 315 MW supercritical plant.[27] In October 2021 the DOE listed a March 2025 commissioning date for Unit 4.[28]
As of April 2023, the DOE list of existing power plants reported that Unit 3 had a capacity of 351.8 MW. [13]
Proposed Unit 5 Expansion
In January 2021, Masinloc Power Partners announced plans to construct an additional 315 MW supercritical coal-fired generator at the Masinloc power station. The project is expected to cost approximately US$890 million.[29] The company expects construction to begin in the second half of 2021, with commercial operation targeted for 2024.[30] In October 2021 the DOE listed a September 2025 commissioning date for Unit 5.[28]
2023: Continued development of Units 4 & 5
In February 2023, the DOE reported an updated 350 MW capacity for Units 4 and 5. [31]
Planet imagery shows the development of ground preparation for Units 4 and 5 from 2022 to 2023.
As of September 2023, the Philippines DOE had pushed back the target commercial operation date of Unit 5 from 2025 to 2026.[32] An SMC Prospectus report in September 2023 stated that the company had already signed Engineering, Procurement, and Construction (EPC) contracts for the construction of Units 4 and 5.[33]
In February 2024, the Philippines DOE noted that the two units may face delays due to "Right of Way" issues with the related transmission line, but the target commercial operation dates remained October 2025 and April 2026 for Units 4 and 5, respectively.[34] The same note remained in the DOE's list of power projects as of June 2024.[35]
In September and October 2024, the DOE listed Units 4 and 5 with targeted commercial operation dates in August 2025 and April 2026 respectively.[36][37] Reporting indicated that construction of Unit 4 was underway.[38]
Financing
Unit 3: In December 2015, the project reached financial closure after it secured US$525 million in loans from the Development Bank of the Philippines, Philippine National Bank, Rizal Commercial Banking Corporation, and Security Bank. US$175 million in equity was provided by AES Corporation.[39][40][41] AES 2015 annual report and several media sources clarified that this financial close was for 335MW (gross) expansion unit (i.e. Unit 3)[42][40][41] adjacent to the existing 640MW plant, although IJ Global stated that the the proceeds are to be used to double the size of 660MW Masinloc.[39]
In 2017, the Philippine Movement for Climate Justice lodged a formal complaint against the International Finance Corporation (IFC) for its involvement in Philippine coal-fired power stations. The complaint alleged that the IFC had funded these projects through its financial support to Rizal Commercial Banking Corporation (RCBC). The Masinloc power station expansion was one of 11 projects for which the IFC's involvement was found to be sufficient to trigger the IFC's internal accountability process.[43]
Acquisition Finance: In March 2018 San Miguel Corporation acquired 100% of Masinloc Power Partners Co. Ltd. by acquiring AES's 51% share for $1.05 billion and EGCO's 49% share for $850 million.[44] San Miguel Corporation was able to acquire Masinloc Power Partners Co. Ltd. by using money from three term loans, totalling USD $1.9 billion. One loan expired in 2021 and two expired in March 2023. These loans were provided by Sumitomo Mitsui Banking Corporation, Mizuho Financial Group and Standard Chartered Bank.[45]
In February 2024, four environmental and human rights groups filed a complaint with a UK government agency against Standard Chartered over its role in financing four coal plants in the Philippines, including Masinloc power station, Limay power station, Davao San Miguel power station, and the Dinginin power station expansion. The Philippine Movement for Climate Justice, Inclusive Development International, Recourse, and BankTrack complaint stated that local communities near the plants "have suffered economic and physical displacement, adverse health impacts, threats and intimidation of community activists" and were seeking compensation for those affected. The complaint requests the National Contact Point for Responsible Business Conduct (NCP), a government unit responsible for compliance with OECD Guidelines for Multinational Enterprises, to facilitate dialogue with the complainants and several local community members to resolve the issues.[46][45]
SMC Termination of Contracts with Meralco
In March 2023, it was reported that San Miguel Corporation (parent company of the Masinloc power station) had terminated supply contracts with Manila Electric Company (Meralco), which would have included supply from the proposed Units 4 and 5 scheduled for COD in May 2025. [47] It was reported that "PSA termination was resorted to by SMC because the Energy Regulatory Commission (ERC) failed to act on its PSA applications, despite the two years that these have been pending with the agency". [47]
Ownership
In July 2017, AES announced that it would sell its 51% ownership stake in Masinloc.[48] Potential bidders for the facility as of October 2017 were Meralco, San Miguel Corporation, and Aboitiz Power Corporation.[49]
In March 2018 San Miguel Corporation assumed 100% ownership of Masinloc Power Partners Co. Ltd. by acquiring AES's 51% share for $1.05 billion and EGCO's 49% share for $850 million.[44]
Environmental Impact
In March 2018 members of the environmental group Oyon Bay Protector (OBP) claimed that construction on the Masinloc expansion had destroyed large areas of coral and marine life in Masinloc Bay.[50] “The unauthorized massive reclamation activities of MCPP in Masinloc town must be stopped immediately since they violated several provisions of the national integrated protected areas system act of 1992,” said OBP chairman Joey Marabe.[50]
Outages and impact on grid
In May 2024, an analysis by the Center for Energy, Ecology, and Development found that coal- and gas-fired power plants were the leading cause of blackouts in the Philippines between 2019 and 2023. Over half of the forced outages in that time period were attributable to coal plants. Of the eight most unreliable plants, six were coal plants: Calaca power station, San Buenaventura power station, Masinloc power station, Limay power station, Panay power station, and Pagbilao power station. These power stations each had at least 10 incidents of forced outages. The amount of outages was not consistent with age; Masinloc power station Unit 3, which had only been operating for three years, was reportedly offline for 118 days.[51]
Articles and Resources
References
- ↑ https://potent.com.cn/en/info/11.html.
{{cite web}}: Missing or empty|title=(help) - ↑ 2.0 2.1 2.2 (PDF) https://www.doe.gov.ph/sites/default/files/pdf/electric_power/01_Luzon-Committed-Dec-2023.pdf.
{{cite web}}: Missing or empty|title=(help) - ↑ 3.0 3.1 The Hazardous Masinloc Coal-Fired Power Plant, NGO Forum on the ADB blogpost, Feb. 2, 2008.
- ↑ 4.0 4.1 Masinloc Folk Oppose Coal Plant Expansion, Philippine Inquirer, Oct. 19, 2011.
- ↑ Cullen, Shay. Kimi Masa Tarumitzu and Masinloc Power, Philippine Daily Inquirer, July 14, 1992.
- ↑ Townfolks and Greenpeace Protest Japan Export Import Bank, Greenpeace press release, Dec. 3, 1993.
- ↑ Erlich, Reese. Japanese Aid Comes With Strings Attached, Filipinos Say, Christian Science Monitor, Jan. 11, 1994.
- ↑ 8.0 8.1 Bishop, Clergy Lead 4-Year-Old Protest Against Coal Plant, UCA News, July 4, 1994.
- ↑ Summary Environmental Impact Assessment of the Masinloc Coal Fired Thermal Power Plant Project in the Republic of the Philippines, Asian Development Bank, May 1995.
- ↑ Masinloc Coal Power Plant Philippines, GEO, accessed July 2019
- ↑ ADB Told to Stop Pushing for Privatization of RP's Food, Power Sectors, GMA News, April 29, 2008.
- ↑ Greenpeace Activists Attacked in Philippine Coal Plant Protest Against Climate Change in Asia, Greenpeace press release, Nov. 10, 2005.
- ↑ 13.0 13.1 List of existing power plants (grid-connected) as of December 2022 - Luzon Grid, Department of Energy, April 28, 2023.
- ↑ Amy R. Remo, "AES to proceed with $1B Masinloc power plant expansion," Philippine Daily Inquirer, September 30th, 2011.
- ↑ U.S. Energy Giant Remains Upbeat Over Philippine Prospects, Philippine Inquirer, June 8, 2012.
- ↑ Iris Gonzales. AES working on Masinloc coal plant. Philippine Star, 29 Sept. 2014.
- ↑ Private Sector Initiated Power Projects (Luzon), Philippines Department of Energy, Sept. 2014.
- ↑ AES Sells Minority Stake in Masinloc Power Plant and Development Projects in the Philippines to EGCO Group for $453 Million, AES press release, 25 June 2014.
- ↑ EPC contractor appointed for Philippines’ Masinloc, IJ Global, December 2, 2015
- ↑ "EGCO Group Starts the Construction of “Masinloc Unit 3” Coal-Fired Power Project in the Philippines," EGCO Group press release, March 3, 2016
- ↑ POWER Engineers Selected as Owner’s Engineer for the Masinloc Expansion Project in the Philippines, POWER Engineers press release, Aug. 2016.
- ↑ 2018 Private Sector initiated power projects in Luzon (committed), Department of Energy, Republic of the Philippines, September 2018
- ↑ PRIVATE SECTOR INITIATED POWER PROJECTS (LUZON) COMMITTED, Philippine Department of Energy, 31 Mar., 2019
- ↑ PRIVATE SECTOR INITIATED POWER PROJECTS (LUZON) COMMITTED, Philippine Department of Energy, 31 Aug., 2019
- ↑ PRIVATE SECTOR INITIATED POWER PROJECTS (LUZON) COMMITTED, Philippine Department of Energy, 31 Dec., 2019
- ↑ SMC plans 2,135-MW power plants, Manila Standard, Aug. 21, 2020
- ↑ San Miguel expanding Masinloc power plant capacity by 630MW, Power Philippines, Jan. 4, 2021
- ↑ 28.0 28.1 PRIVATE SECTOR INITIATED POWER PROJECTS (LUZON) COMMITTED, Philippine Department of Energy, 31 Oct., 2021
- ↑ Alena Mae S Flores, SMC Global Power expanding Masinloc coal plant by 630 MW, Manila Standard, Jan. 3, 2021
- ↑ MASINLOC POWER PLANT EXPANSION PROJECT, Masinloc Power Partners Co. Ltd., Jan. 2021
- ↑ PRIVATE SECTOR INITIATED POWER PROJECTS (LUZON) COMMITTED, Philippine Department of Energy, April 17, 2023
- ↑ LUZON COMMITTED POWER PROJECTS Philippine Department of Energy, Posted: Sept. 21, 2023
- ↑ SAN MIGUEL CORPORATION Prospectus SMC, Sept. 12, 2023
- ↑ Luzon Committed Power Projects, Philippines Department of Energy, February 22, 2024
- ↑ Luzon Committed Power Projects, Philippines Department of Energy, Posted: June 14, 2024
- ↑ Luzon Committed Power Projects, Philippines Department of Energy, Posted: September 23, 2024
- ↑ Luzon Committed Power Projects, Philippines Department of Energy, Posted: October 14, 2024
- ↑ Success of the Hydrostatic Test for the Supercritical Boiler of Unit 4 at the Masinloc Power Plant of San Miguel Global Power, Philippines, Potent, September 14, 2024
- ↑ 39.0 39.1 "Masinloc II Power Plant Expansion | Transaction | IJGlobal". ijglobal.com. Retrieved 2020-09-22.
{{cite web}}: CS1 maint: url-status (link) - ↑ 40.0 40.1 "https://businessmirror.com.ph/2016/01/27/bpi-leads-consortium-raising-525-million-for-masinloc-power-plant-expansion/". businessmirror.com.ph. January 2016.
{{cite web}}: External link in|title= - ↑ 41.0 41.1 "AES raises $525-M loan for Masinloc plant expansion". philippinepowerinsights.wordpress.com. January 2016.
{{cite web}}: CS1 maint: url-status (link) - ↑ "2015 Annual Report" (PDF). www.annualreports.com. 2016.
{{cite web}}: CS1 maint: url-status (link) - ↑ CAO ASSESSMENT REPORT Regarding Concerns in Relation to IFC’s Investment in Rizal Commercial Banking Corporation (RCBC) – 01 (#30235, #32853, #34115, #37489) in the Philippines, IFC Compliance Advisor Ombudsman, April 2019
- ↑ 44.0 44.1 SMC Global Power completes $1.9-billion Masinloc acquisition, The Philippine Star, Mar. 22, 2018
- ↑ 45.0 45.1 "Complaint to UK National Contact Point on Standard Chartered," BankTrack, February 26, 2024
- ↑ "Standard Chartered targeted in complaint over coal plant funding," Reuters, February 29, 2024
- ↑ 47.0 47.1 SMC terminates 1,800-MW supply contracts with Meralco, Manila Bulletin, March 17, 2023
- ↑ AED plans exit from $1 billion Philippine power plant, Bloomberg, 18 Jul 2017.
- ↑ Meralco to bid alone for AES' coal plant in Zambales, Rappler, 3 Oct 2017.
- ↑ 50.0 50.1 Zambales residents denounce coal plant, Manila Standard, Mar. 23, 2018
- ↑ Can’t Take The Heat?: Examining the Philippines’ Perennial Power Outages Problem caused by Fossil Fuels, Center for Energy, Ecology, and Development, May 13, 2024
Additional data
To access additional data, including an interactive map of coal-fired power stations, a downloadable dataset, and summary data, please visit the Global Coal Plant Tracker on the Global Energy Monitor website.
