Ventanas power station (Termoeléctrica Ventanas) is an operating power station of at least 544-megawatts (MW) in Puchuncaví, Valparaíso, Valparaíso Region, Chile with multiple units, some of which are not currently operating. It is also known as Campiche power station (Unit 4), Nueva Ventanas power station (Unit 3), Ventanas Campiche power station.
Location
Table 1: Project-level location details
| Plant name | Location | Coordinates (WGS 84) |
|---|---|---|
| Ventanas power station | Puchuncaví, Valparaíso, Valparaíso Region, Chile | -32.7512, -71.4825 (exact) |
The map below shows the exact location of the power station.
Unit-level coordinates (WGS 84):
- Unit 1, Unit 2, Unit 3, Unit 4: -32.7512, -71.4825
Project Details
Table 2: Unit-level details
| Unit name | Status | Fuel(s) | Capacity (MW) | Technology | Start year | Retired year |
|---|---|---|---|---|---|---|
| Unit 1 | retired | coal: subbituminous | 120 | subcritical | 1964 | 2020 |
| Unit 2 | retired | coal: subbituminous | 220 | subcritical | 1977 | 2023[1] |
| Unit 3 | operating | coal: subbituminous | 272 | subcritical | 2010 | 2025 (planned) |
| Unit 4 | operating | coal: subbituminous | 272 | subcritical | 2013 | 2025 (planned) |
Table 3: Unit-level ownership and operator details
| Unit name | Owner | Parent |
|---|---|---|
| Unit 1 | AES Andes SA [100%] | AES Andes SA [100.0%] |
| Unit 2 | AES Andes SA [100%] | AES Andes SA [100.0%] |
| Unit 3 | AES Andes SA [100%] | AES Andes SA [100.0%] |
| Unit 4 | AES Andes SA [100%] | AES Andes SA [100.0%] |
Financing
- Source of financing: Unit 4: Credit Agricole Group and BNP Paribas Fortis
Background
The four-unit Ventanas project dates back to 1964, when the first 120 MW unit (Ventanas 1) was installed.[2][3][4][5] This was followed by 220 MW Ventanas 2 in 1977.[2][4][5] The 272 MW-each Ventanas 3 (also known as Nueva Ventanas) and Ventanas 4 (known as Campiche) were added in 2010 and 2013, respectively, making the Ventanas complex one of the largest in Chile.[2][5] All four units are fueled by subbituminous coal imported via the attached coal port.[2][6]
In April 2021, plant owner AES Gener changed its name to AES Andes.[7][8]
Planned retirement
Units 1 & 2
In June 2019 the Chilean government announced that Unit 1 would be retired by 2022 and Unit 2 would be retired by 2024 as part of a plan to reduce the country's annual CO2 emissions from the current 30 million tonnes (tons) to four million by 2024.[9][10] Plant owner AES Gener confirmed decommissioning dates of November 2022 and May 2024 in its 2019 annual report.[11]
In December 2019 AES Gener reached an agreement with the Chilean government to move the retirement date for Unit 1 to the end of 2020 and the retirement date for Unit 2 to the end of 2022.[4]
On December 29, 2020, Ventanas Unit 1 was decommissioned after 56 years in operation. Despite its retirement, Unit 1 retained 'strategic reserve' status, meaning that it could still theoretically be reactivated to provide backup power supply under exceptional circumstances that put the security and sufficiency of Chile's electrical grid at risk.[3] AES reportedly received significant sums of money between December 2020 and June 2022 to maintain Ventanas Unit 1 in working order under the "strategic reserve" agreement, yet the company did not generate any electricity from Unit 1 during this 18-month period, most notably failing to reactivate Unit 1 as required in response to an August 5, 2021 request from Chile's national electricity agency CEN.[12]
In June 2022, AES Andes requested authorization from the Chilean electrical authority CNE to definitively remove Ventanas Unit 1 from reserve status and shut it down completely.[13][14] In July 2022, Chile's National Energy Commission passed a resolution officially authorizing definitive shutdown of Unit 1.[15]
As of mid-2020, Unit 2 remained on schedule for retirement in December 2022.[16] However, in December 2021, Chile's National Energy Commission requested that AES Andes postpone the closure of Ventanas 2 until 2023 to ensure grid reliability.[17][18][19]
In May 2023, a notice from the Chilean Ministries of Mining and the Environment indicated that Ventanas II was still on track to shut down in the second semester of 2023.[20] The announcement included a note that the employees of Ventanas II would be "relocated or will take advantage of early retirement."[20]
In August 2023, AES Andes announced that it had filed a formal request with Chile's national energy commission (CNE) for exemption from a previously agreed requirement to give 24-month advance notice before disconnecting Ventanas 2.[21][22] If approved, AES Andes' request would allow Ventanas 2 to be retired as early as December 31, 2023[23], nullifying an earlier agreement intended to keep the unit on "Strategic Reserve" status through 2025.[24]
By the end of December 2023, it was reported that a retirement ceremony had taken place for Unit 2.[25]
Units 3 & 4
According to Chile's national decarbonization plan, Nueva Ventanas (Unit 3) and Campiche power station (Unit 4) were to cease operations no later than 2040, though the specific decommissioning dates were yet to be determined. AES Gener agreed to consult with the government every five years to renew details of the plan for Units 3 and 4, taking into account system stability requirements, energy costs, and environmental goals.[5]
In July 2021, AES Andes announced that it would officially retire Ventanas Units 3 and 4 (Nueva Ventanas and Campiche) as early as January 2025, provided that Chile's grid requirements could be met by other sources of electricity.[7][26][27][28]
According to the Chilean government's 2024 decarbonization plan, Units 3 and 4 (Nueva Ventanas and Campiche) were still planned for retirement in or by 2025.[29][30]
AES Andes announces sale to Quintero Energía
In December 2024, AES Andes announced the sale of the Ventanas power station to Quintero Energía SpA.[31] While the power station's new owners stated that they would align operations with the government's decarbonization plan, reporting indicated that the coal plant would continue operating beyond the previous owners' retirement plans, which had scheduled the two units for retirement in or by 2025.[32][33]
Environmental Impact
The latest addition to AES Gener's Ventanas coal-fired complex, Unit 4 (Campiche) was originally scheduled for completion in May 2011. However, in June 2009, Chile's Supreme Court ordered that construction be halted, citing improper zoning of the plant. AES Gener had already completed 40% of the $500 million project before it was halted. Subsequent regulatory changes allowed construction of the plant to resume, but the project was again suspended in early 2010 as Puchuncaví municipality took legal steps against the plant due to environmental concerns. In July, 2010, AES Gener reached an agreement with Puchuncaví to renew construction of Campiche, promising in return to invest nearly US$80 million in environmental improvements of the company's local thermal power plants, in public projects and forestation.[34][35] The plant was brought online in March 2013.[36]
In late December 2013, several tons of sardines washed up dead on Ventanas beach near the plant, spurring renewed controversy over Campiche's environmental impact and prompting calls for suspension of operations.[37][38][39]
In June 2022, Chile's environmental regulator SMA halted operations at the Ventanas power plant and the adjacent Codelco copper smelting plant, after excessively high sulfur dioxide emissions were detected.[40] More than 100 residents in the surrounding area - mostly children - fell ill, and classes were suspended at local schools.[41] According to an AES Andes spokesperson, the SMA conducted a site inspection and determined that the power plant was not responsible for the incident.[42]
In November 2024, CREA published a report estimating that from 2013 to 2020, the Ventanas power station's emissions were linked to approximately 1,117 asthma-related emergency room visits, approximately 563 human deaths, and a public health cost equivalent of USD 1.4 billion.[43]
Opposition
Plant owner AES Andes (formerly AES Gener) has been the subject of heavy criticism in recent years from Chilean environmental groups.
In April 2018 a lawsuit was filed against AES Gener by a group of 259 fisherman, demanding damages as a result of AES Gener dumping coal in the bay of Ventanas.[44]
In April 2019 a protest was staged in Ventanas against industrial pollution, including a plan by AES Gener to use additional desalinated sea water at the Ventanas power station.[45]
In 2021, the groups Chile Sustentable, Fundación Terram and Alianza Chao Carbón published reports documenting the company's negative impact on human rights, health, and the environment.[46][47] Alianza Chao Carbón has taken a lead role in criticizing AES Gener for not committing to a precise shutdown date for all of its Chilean coal operations, noting that it is among the few companies that have failed to do so.[48]
Financing for Unit 4
In March 2013, a financing agreement with Credit Agricole Group and BNP Paribas Fortis was closed; however, the amount of the financing was not disclosed.[49]
